5005 Aluminum Sheet

Alloy:5005
Width:500-2200mm
Thickness:0.2-350mm
Port of Loading:Qingdao
Certificated:ISO9001

5005 ALUMINUM SHEET DESCRIPTION:

5005 aluminum sheet is a non-heat treatable alloy with magnesium content. It can be strengthened (hardened) by cold working. It scores well in weld-ability, formability, and corrosion resistance.

Mg is the principal element in the 5005 aluminum sheet and when it used as main alloying element or combined with Mn, high strength and no-heat treatable properties can be realized. 5005 aluminum sheet of Haomei aluminum has many tempers available, such as 5005-H12, 5005-H14, 5005-H16, 5005-H18,5005-H22, 5005-H24, 5005-H32, 5005-H34, 5005-H36, 5005-H38, etc.

5005 ALUMINUM SHEET CHEMICAL COMPOSITION:

ElementsSiFeCuMnMgCrZnTiOthersAl
Content(max)0.300.700.200.200.50-1.100.100.25-0.15Remain

5005 ALUMINUM SHEET PROPERTIES BY TEMPER:

AlloyFormTemperTensile StrengthYield StrengthElongation
5005sheetH12201910
5005sheetH1423226
5005sheetH1626255
5005sheetH1829284
5005sheetH32201711
5005sheetH3423208
5005sheetH3626246
5005sheetH3829275

5005 ALUMINUM SHEET APPLICATION:

Buildings – Roofing, Cladding, Corrugated Sheet

Signage, Road Signs & Name Plates

Food & Chemical Equipment

Furniture

Anodised Parts

HVAC Equipment

Packaging

Pipe and Tube

Can Bodies

RELEVANT GRADE OF 5005 ALUMINUM SHEET:

Relevant grade of 3004 Aluminum Sheet

5005 ALUMINUM SHEET PACKING:

5005 aluminum sheet of Haomei Aluminum. meet the export standard. Plastic film and brown paper can be covered at customers’ need. What’s more, wooden case or wooden pallet is adopted to protect products from damage during the delivery. There are two kinds of packaging, which is eye to wall or eye to sky. Customers can choose either of them for their convenience. Generally speaking, there are 2 tons in one package, and loading 18-22 tons in 1×20′ container, and 20-24 tons in 1×40′ container.

As a China-based 5005 aluminum sheet manufacturer and supplier, we at Haomei also produce aluminum slit coil, aluminum strip, coated aluminum coil, aluminum plate, anodising aluminum sheet, embossed aluminum sheet, etc. For more detailed information, please continue browsing our website or feel free to contact us directly.
