| Alloy: | 3105 |
| Width: | 500-2600mm |
| Thickness: | 0.2-350mm |
| Port of Loading: | QingDao,China |
| Certificated: | ISO9001 |
3105 ALUMINUM SHEET DESCRIPTION:
3105 aluminum sheet with 98% pure aluminum and slight alloy additions for strength. 0.3% of copper is added to 3105 aluminum sheet, so the conductivity turns out to be 41%. For its contents and processing technologies, 3105 aluminum sheet is light in weight and it has semi-smooth surface. Besides, it is not hardened by heat treatment.
Mg, Mn and Si are added to 3105 aluminum sheet, thus, it has excellent correction resistance, formability and welding characteristics. Besides, it has average mechinability and it can be increased in harder tempers than in annealed condition. Oil lubricants should be used for all machining operations. The forming characteristics of 3105 aluminum sheet are pretty good by all conventional processes regardless of temper. But 3105 aluminum sheet does not respond to heat treatment except for annealing during cold working. The cold working characteristics are very good, even in the harder cold working tempers. For all the features above, 3105 aluminum sheet has a vast application in many field.
3105 ALUMINUM SHEET CHEMICAL COMPOSITION:
| Elements | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Others | Al | |||
| Content(max) | 0.6 | 0.70 | 0.30 | 0.3.-0.80 | 0.20-0.80 | 0.20 | 0.40 | 0.10 | 0.15 | remain | |||
3105 ALUMINUM SHEET MECHANICAL PROPERTIES:
| Material | Temper | Tensile Strength (N/mm²) | Yield Strength (N/mm²) | Elongation on 50mm | |||
| 0.5 mm | 0.8mm | 1.3mm | 2.6mm | ||||
| 3105 | 0 | 110-155 | - | 16 | 18 | 20 | 20 |
| 3105 | H12 | 130-175 | 115 | 2 | 3 | 4 | 5 |
| 3105 | H14 | 160-205 | 145 | 2 | 2 | 3 | 4 |
| 3105 | H16 | 185-230 | 170 | 1 | 1 | 2 | 3 |
| 3105 | H18 | 215 min | 190 | 1 | 1 | 1 | 2 |
RELEVANT GRADE OF 3105 ALUMINUM SHEET:
Relevant grade of 3004 Aluminum Sheet | |
3105 ALUMINUM SHEET PACKING:
3105 aluminum sheet of Haomei Aluminum. meet the export standard. Plastic film and brown paper can be covered at customers’ need. What’s more, wooden case or wooden pallet is adopted to protect products from damage during the delivery. There are two kinds of packaging, which is eye to wall or eye to sky. Customers can choose either of them for their convenience. Generally speaking, there are 2 tons in one package, and loading 18-22 tons in 1×20′ container, and 20-24 tons in 1×40′ container.
As a China-based 3105 aluminum sheet manufacturer and supplier, we at Haomei also produce aluminum slit coil, aluminum strip, coated aluminum coil, aluminum plate, anodising aluminum sheet, embossed aluminum sheet, etc. For more detailed information, please continue browsing our website or feel free to contact us directly.
